CB2 - HTm 3/6 - 2x2 HP single-phase pressure group

2 x 1.5 kW (2 x 2 HP) motor. Flow rate up to 180 l/min (10.8 m³/h). Head up to 97 m.

€2,254.56 Tax included

1848 Tax excluded

€4,099.20-45%

Make a purchase proposal

Your Offer is sent.

Your Offer is accepted, please check your inbox.

CB2 - HTm 3/6 - 2x2 HP single-phase pressure group
  • Use dot instead of comma

Loading

Description

The Pedrollo CB2 - HTm 3/6 pressure booster set is suitable for residential and commercial water supply, for irrigation and for the movement of clean water in general, including in the industrial field.

Consisting of two HTm 3/6 electric pumps, two pressure switches, and an E2 electrical panel. Two manifolds for the suction and delivery ports are also supplied.

Each unit is equipped with ball valves on the delivery and suction sides, and non-return valves on the suction side.

The pressure switches, on the other hand, are used to turn the pumps on and off based on the setting.

The E2 control panel provides protection against dry running.

The CB2 - HTm 3/6 pressure group has a flow rate ranging from 10 to 180 litres per minute and a head from 48 to 97 metres.

Data sheet
Brand Pedrollo
Reference CB2 - HTm 3/6
In stock 50 Items
MPN KCHT10306A1
Motor connection
SINGLE-PHASE
Power (Kw)
3
Power (HP)
4
Absorption at 230V (A)
21.0
Suction mouth
2"
Delivery mouth
2"
Minimum flow rate (l./min.)
10
Max. flow rate (l./min.)
180
Min. head (m.)
48
Max. head (m.)
97
Height (cm)
85.4
Width (cm)
53.0
Depth (cm)
73.2
Weight (Kg)
102
Attachments

Technical data sheet CB2

Construction and operating characteristics. Working curves, limits of use and dimensions of the CB2 Pedrollo pumps.

Download (2.73MB)

CB2 - HTm 3 models and performances
