CB2 - MK 5/4 - Three-phase pressure group 2x1.5 HP
2 THREE-PHASE ELECTRIC PUMPS.
Two 1.1 kW (1.5 HP) motors. Flow rate up to 240 l/min (14.4 m³/h). Head up to 56 m.
The CB2 - MK 5/4 pressure group from the CB2-CP series by Pedrollo is designed so that one or both electric pumps start up at each increase in demand.
It allows intelligent water management and consequent water and energy savings.
Suitable for pumping clean water or aqueous solutions that do not chemically or mechanically damage the components.
The 2 electric pumps are connected in parallel in a unit for connection to the water mains or to a primary collection tank and managed by mechanical pressure switches.
The CB2 - MK 5/4 pressure group is made up of 2 MK 5/4 electric pumps, a base, a pressure switch and an electronic panel.
- Motor connection
- THREE-PHASE
- Power (Kw)
- 2.2
- Power (HP)
- 3
- Current consumption at 400V (A)
- 5.6
- Suction mouth
- 2"
- Delivery mouth
- 1" 1/2
- Minimum flow rate (l./min.)
- 20
- Max. flow rate (l./min.)
- 240
- Min. head (m.)
- 20
- Max. head (m.)
- 56
- Height (cm)
- 69.5
- Width (cm)
- 53
- Depth (cm)
- 86.8
- Weight (Kg)
- 59
- Warranty (years)
- 2
CB2 - MK models and performances
|
|
|
|
|
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
